RIALTO-PCB – Assy PCB Amp HPX UcD250LP

R1,487.53

4 in stock

SKU: RIALTO-PCB Category:

Description

The UcD250LP OEM amplifier module emerges as a paragon of high-performance Class-D amplification, meticulously engineered for versatility across an expansive array of audio applications. Tailored to excel in environments ranging from Active Studio Monitors to sophisticated Public Address systems, Line Arrays, and Immersive Audio setups, this amplifier module is a testament to innovation, reliability, and great audio quality.

With an unwavering commitment to versatility, the UcD250LP OEM amplifier module effortlessly caters to the diverse needs of professionals. From the intricate demands of Public Address systems to the discerning requirements of studio and home playback scenarios, this amplifier module is poised to deliver exemplary performance with finesse.

The Low Profile OEM design extends the boundaries of performance with its thoughtfully crafted compact design. This attribute is not merely an aesthetic consideration; it serves a practical purpose by addressing the constraints of space-limited applications. The amalgamation of its low-profile design and great audio capabilities positions the UcD250LP OEM as the epitome of sophistication in amplifier technology.

Recognizing the growing demand for audio solutions that seamlessly integrate into space-limited environments, the UcD250LP OEM shines as an ideal choice. Its low-profile design not only meets the spatial constraints of modern setups but also renders it perfect for multichannel applications, where a compact footprint and uncompromised audio quality are paramount.

The UcD250LP OEM amplifier module is not just a technical marvel; it has earned its place as a preferred choice through rigorous testing and trials. Professionals across the world who demand a compact design with great performance and proven reliability have chosen the UcD250LP OEM for many years as their go-to solution.

Additional information

Weight 2 kg
Dimensions 29 × 21 × 6 cm
Brand

Overview

Highlights

  • • Flat, fully load-independent frequency response
  • • Low output impedance
  • • Very low, frequency-independent THD
  • • Very low noise
  • • Fully passive loop control

Features

  • • Unbuffered input
  • • Runs on unregulated +/- rails
  • • Pop-free start and stop control
  • • Differential audio input

Protections

  • • Overcurrent protection
  • • Overvoltage protection
  • • DC-fault detection
  • • Short circuit protection

Possible applications

  • • Active Loudspeakers, for home and professional use
  • • Power Amplifiers, for home and professional use
  • • Line Array and Immersive Systems
  • • Home Theatre Systems
  • • Multichannel Power Amplifiers

Downloads

UcD250LP_OEM_R7

Specifications

Bridgable: Yes
Output Power (2Ω): Not supported
Output Power (4Ω): 250W
Output Power (8Ω): 180W
Channels: 1
Distortion: 0.02% 20hZ < f < 20kHz. Pout = 1W
Output Noise: 20µV (Typ) – 25µV (Max)
Power bandwidth: 20Hz – 35kHz
Freuquency Response: DC 56kHz +0/-3dB. All loads
Output impedance: 22mΩ (Max) – f < 1kHz, 90mΩ (Max) – f < 20kHz
Current limit @: 17A
HxR Ready: No
OpAmp: No
Over voltage protection @: 72V
SMPS Voltage +/-: 60V
Compatible SMPS: SMPS3kA400, SMPS400A400, SMPS1200A400
Technology: UcD™
Family: UcD™ family
